    IP30 Addressable Fire Alarm Panel Conventional Manual Call Point

    Ask Lasest Price
    Brand Name : HiYi
    Model Number : D135C
    Certification : CE
    Price : USD 4.3 - 6.3 / set
    Payment Terms : T/T, Western Union, MoneyGram, D/P, D/A, L/C
    Supply Ability : 1000 SET / week
    Delivery Time : 1-10 work days
    • Product Details
    • Company Profile

    IP30 Addressable Fire Alarm Panel Conventional Manual Call Point

    Manual Alarm Point Addressable Fire Alarm System CE ROHS Manual Call Point


    D135C Asenware Conventional Manual Call Point


    OVERVIEW

    The D135C conventional manual call point is designed to be use with an intelligent two-wire control system. If it is pressed after a fire is manually confirmed, an alarm signal may be sent to a fire alarm control system which will, after receiving the alarm signal, display the equipment status of the manual call points. When the manual call point is operating normally, the red indicator will blink; when there is a fire alarm, it will remain lit.


    IP30 Addressable Fire Alarm Panel Conventional Manual Call Point


    FEATURES & BENEFITS

    • Semi-flush or surface mounting
    • Simple key to reset operating element (no broken glass)
    • LED indicator
    • Complete functional test with every activation
    • Meets all requirements of latest EN54 part 11

    IP30 Addressable Fire Alarm Panel Conventional Manual Call Point


    PROJECT

    Fire alarm system is mostly used for laying fire system in office and commercial places. Any building needs fire alarm system, which can effectively prevent the occurrence of fire and give warning from the source.


    IP30 Addressable Fire Alarm Panel Conventional Manual Call Point


    PRODUCT PARAMENTERS

    ModelD135C
    Main VoltageZone 24V or 12V
    Operating currentmonitoring status≤20uA, alarm status≤15mA
    ApplicationFor indoor use only
    WiringThe promise of two bus system(Zone +, Zone -)
    Protection classIP30
    IndicatorRed alarm indicator flashes when it is under normal condition, press the manual button lit work
    EnvironmentalClass A temperature range: -5 to 40°C (23~104°F)
    Humidity: 5 to 95% RH, non-condensing
    Materials and colorsABS, red
    Mating PanelAW-CFP2166 fire alarm control panel
    Size99mm* 92mm* 66mm(with cover)
    WeightAbout 95g
