    IP54 Mini Handheld Laser Methane Detector 32A GPS ATEX Location Tracking Bluetooth

    Ask Lasest Price
    Brand Name : HiYi
    Model Number : SA3C32A‐NE SA3C32A-BE
    Certification : Ex, АТЕХ 11 2 G Ех ib op-pr/op-is IIA Т1 Gb, 1 m2 Ех ib op-pr/op-is, СЕ
    Price : USB 15000 - 18000/set
    Payment Terms : D/P, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10000 set/month
    Delivery Time : 3-7 days
    • Product Details
    • Company Profile

    IP54 Mini Handheld Laser Methane Detector 32A GPS ATEX Location Tracking Bluetooth

    HiYi Laser Methane Mini 32A GPS ATEX Location Tracking Bluetooth Handheld Laser Methane Gas Detector
    Crowcon Laser Methane Mini Long-Range Methane Detector

    OVERVIEW

    Laser Methane mini (LMm) is a compact handheld detector for the detection of methane gas at a safe distance (0-100m).
    Utilising laser technology, methane leaks are located by pointing the laser beam towards the suspected leak, or along the survey line.


    This revolutionary technology removes the need to access elevated places, reducing cost and improving the speed of leak detection activities.
    LMm is ideal for use in industrial, commercial and research environments, anywhere that methane could be present and in need of locating or monitoring.

    LMm is easy to operate and requires no maintenance. An automatic self-check during start-up ensures consistent performance and reliability every time unit are turned on. The green laser guide light is highly visible even under strong sunlight simplifying the task of locating leaks.


    The Bluetooth option combines the benefit of LMm with additional data storage functions, allowing connection to an Android device using the GasViewer app.
    Important data including gas level, time, date and location are combined and can then be saved or emailed to a central point.


    IP54 Mini Handheld Laser Methane Detector 32A GPS ATEX Location Tracking Bluetooth


    SPECIFICATIONS


    Gas to be measured
    Methane (CH4) and methane-containing gases (natural gas or similar)
    Measurable level
    1~50,000ppm/m
    Measurable accuracy
    ±10% Measuring range : 100 to 1,000ppm-m
    Measuring Speed
    0.1second
    Measurable distance
    0.5m to 30m
    0.5m to 100m (using a reflect sheet)
    Power Supply
    Dedicated rechargeable battery
    Continuous Operation Time
    Approx4hours (at25℃, Display level : 4 Blinking Mode)
    Laser Safety Class
    Guide light : Class3R
    Measurement light : Class1 (IEC 60825-1 : 2007)
    Intrinsically Safe Category
    (EN 60079-0 : 2012 , EN 60079-11 : 2012,EN 60079-28 : 2007)
    EMC
    EN 61326-1 : 2013
    Environmental Conditions
    Operating temperature range:–17~50℃
    Splash-proof and dust-proof structure (IP54)
    Dimension and weight
    70(W)×179(D)×42(H)mm
    600g or less (including a battery)

    FEATURES & BENEFITS
    • Remote measurement and detection, up to 100 meters (using a reflect sheet)
    • No specialist or special access equipment required to detect leaks
    • ATEX approved for industrial use and now includes mining applications
    • Two versions available with & without Bluetooth
    • Real-time data display
    • GPS location tracking
    • Data storage for traceability
    • Ability to capture and store images

    IP54 Mini Handheld Laser Methane Detector 32A GPS ATEX Location Tracking Bluetooth


    APPLICATION

    Laser Methane Detectors for natural gas leak detection remote monitoring of elevated methane gas concentrations in ambient air.
    It is specifically designed for the constant scanning and monitoring of mission-critical areas such as Leak detection, Emission monitoring , Gas line surveys, Tank inspections, Landfill emission monitoring, Plant safety audits.


    IP54 Mini Handheld Laser Methane Detector 32A GPS ATEX Location Tracking Bluetooth
