    GT44 Flammable Gas Leak Detector

    GT44 Flammable Gas Leak Detector PPM LEL %VOL Sniffer Portable Combustible Gas Detector

    GMI GT SERIES MULTI PURPOSE GAS DETECTORS


    OVERVIEW

    GMI GT Series is a multi-functional gas analyser range comprising of five models; GT-40, GT-41, GT-42, GT-43 and GT-44. Each detector can be used for several different applications, eliminating the requirement for separate instruments for different jobs. Seven functions are possible, gas leakage, confined space entry (safety), purging, pressure leak tightness, bar hole testing, Carbon Monoxide detection and gas sniffing. Portable handheld instruments aimed to meet most gas detection needs in one instrument, built to be durable and easy to use.


    The Integral pump draws the sample in and includes a pressure sensor for gas flow detection. A hydrophobic filter protects the sampling system. Toxic gases are detected by electrochemical cells. Methane is detected by three sensors types: Semiconductor for ppm range, Catalytic Bead, 0-100% LEL and volume measurement by a Thermal Conductivity sensor.


    FEATURES & BENEFITS
    • Multi-application Gas Detector.
    • PPM , LEL and Volume ranges for CH4 leak detection.
    • Manual or automatic datalogging.
    • Audible visual ‘Ticker’ (Geiger) indication on ppm range.
    • Alarms audible > 80db and visible LED flashing on both sides of casing.
    • Large button operation with display prompts.
    • Integral flashlight.
    • Rechargeable or Alkaline battery (8 hours operation either). Charging is by plug or docking station.
    • Complete with rugged Polycarbonate case, IP54 rated suitable for outdoor use

    GT44 Flammable Gas Leak Detector


    SPECIFICATION

    Mode
    GT44
    Gas
    Methane flammable gas
    Sensor 1
    Semiconductor
    Range
    0-10,000ppm (1ppm)
    Sensor 2
    Catalytic Bead
    Range
    0-100% LEL (1%LEL)
    Sensor 3
    Thermal Conductivity Sensor
    Range
    0-100% Vol ( 1%%Vol)
    Dimensions
    290 x 95 x 43 mm /
    11.4 x 3.7 x 1.7” (Excl. Probe)
    Weight
    0.78 kg /
    1.7 lbs (Incl. Probe & Batteries)
    Display
    LCD with backlighting
    Humidity
    0-95% non condensing
    Alarms
    High visibility LEDs on both sides of instrument , 85 db audible alarm
    All alarms user programmable via password protected menu
    Sampling
    Integral pump with pressure sensor for flow fail detection. Sample path is protected by a hydrophobic filter.
    Response Time
    T90 < 30 seconds
    Rating
    IP54 (Dust protected and splashproof)
    Battery
    3 ‘C’ type batteries – LR14 alkaline or rechargeable
    Battery Life
    8 hours continuous alkaline or rechargeable
    Construction
    High impact polycarbonate ABS blend
    Certification
    UL 913 Class I, Div 1, Groups C, D CSA Class I, Groups C, D C22.2 No. 152 SIRA05 ATEX II 2G EEx iad IIB T3 IECEx Exiad IIB T3

    APPLICATION

    The detector is widely used infruit ripening, cold storage, agricultural research center, university, etc.


    The detector can effectively predict the concentration of dangerous gas alarm, to ensure that the safety of staff life is not threatened, production equipment is not lost.
